QUICKSURFACE for SOLIDWORKS add-in - 1 letni najem

QUICKSURFACE for SOLIDWORKS is a powerful reverse engineering add-in for SOLIDWORKS 3D CAD.

• Work inside SOLIDWORKS Desktop 3D CAD
• Import large scans to SOLIDWORKS
• Meshes as native SOLIDWORKS features
• Polygon reduction and smoothing
• Unroll scan
• Extract reference geometry (incl. symmetry plane)
• Align to space, to CAD
• Multi-scan alignment
• Cross-sections: parallel, rotational, outline
• Fit lines/arcs & complex profiles for 2D sketching
• 3D sketching on scan data
• Best-fit surfaces
• Freeform surface modelling
• Real-time accuracy analyser
• 3D colour map: CAD vs. Scan
• One-click freeform
